Lycoming At Overhaul Parts Replacement List - O-540-B Series E Series G1A5 H Series
| Vendor Part Number | Quantity Needed | Description | Part Number | Price Each | Quantity to Buy |
|---|---|---|---|---|---|
| SL71569-1 | 1 | Engine Gasket Set | 08-11861 | $550.00 | |
| SL3601-SC | 6 | SL3601-SC | 08-11751 | $158.75 | |
| SL13444-1 | 6 | SL13444-1 | 08-11595 | $140.80 | |
| SL19001A | 6 | Exhaust Valves | 08-11697 | $396.00 | |
| MS13997-3 | 12 | Exhaust Valve Retaining Rings | 08-10802 | $9.80 | |
| SL78290 | 12 | Hydraulic Plunger Assemblies | 08-12007 | $130.75 | |
| SL13884A | 2 | Bearing Inserts (Main) | 08-11607 | $270.95 | |
| SL11020 | 6 | Bearing Inserts (Rear & Intermediate) | 08-11521 | $94.85 | |
| SL12186 | 12 | Connecting Rod Nuts | 08-11567 | $6.50 | |
| SL-STD-2209 | 1 | Crankshaft Gear Bolt | 08-12038 | $27.50 | |
| SL73810 | 4 | Counterweight Bushings | 08-11915 | $21.50 | |
| SL78528 | 1 | Oil Pump Bodies | 08-12008 | $550.00 | |
| SL18109A-S | 1 | Oil Pump Gears | 08-11683 | $763.00 | |
MS35333-40 | Washer 1/4” | MS35333-40 | $0.05 | ||
| MS35333-41 | Washer 5/16” | AN936-A516 | $0.08 | ||
MS35333-42 | Washer 3/8” | MS35333-42 | $0.12 | ||
| MS35333-43 | Washer 7/16” | AN936-A716 | $0.18 | ||
| SL13792 | 1 | Oil Seal Crankshaft | 08-00292 | $30.50 | |
| SL14260 | 1 | Oil Seal Tach Drive | 08-11625 | $11.50 | |
| SL-STD-208 | 1 | Oil Seal Vacuum Pump | 08-12033 | $14.50 | |
| SL12136 | 4 | Magneto Drive Cushions | 08-11566 | $6.55 | |
| SL53E19600 | 1 | Thermostatic Bypass Valves | 08-11771 | $496.00 | |
| SL12272 | 6 | Lock Plates Shroud Tube | 08-11568 | $1.70 | |
| SL71667 | 1 | Lock Plates Fuel Pump Idler | 08-11866 | $4.35 | |
| SL73383 | 1 | Lock Plates Alt Bracket | 08-11912 | $5.35 | |
| MS16625-2081 | 1 | Retaining Rings Camshaft | 08-10806 | $1.84 | |
| SL69603 | 6 | Engine Hoses Intake | 08-11844 | $12.50 | |
| SL-STD-1821 | 6 | Engine Hoses Oil Drainback Cylinder | 08-12031 | $4.65 |
- JUMP TO
- Overview
- Reviews
- Q&A
- View in Catalog
Overview
|
Lycoming engines are the culmination of hundreds of parts improvements made over the last six decades. In Accordance with Textron-Lycoming Mandatory Service Bulletin 240R |
