Continental At Overhaul Parts Replacement List - TSIO 520 Bb Db Eb Jb Kb Lb Nb Ub Vb Wb

From $0.33 to $700.00
Vendor Part Number Quantity Needed Description Part Number Price Each Quantity to Buy
SA646551-A11Supplement for TSIO-520-BB,DB,EB,VB
08-11451
$26.50
Quantity
SA646552-A11Supplement for TSIO-520-JB,KB,NB
08-11452
$41.90
Quantity
SA633570-A51Major Overhaul Gasket Set W/ Hoses
08-11344
$588.00
Quantity
SA633570-A81Major Overhaul Gasket Set W/ Hoses (TSIO-520-DB,UB)
08-11346
$700.00
Quantity
SA646550-A11Major Overhaul Gasket Set (No Hoses)
08-11450
$268.95
Quantity
SA642917-1VarIntake Hoses
08-11414
$29.50
Quantity
SA6284886Hydraulic Valve Lifter
08-11241
$165.75
Quantity
SA6462776Hydraulic Valve Lifter Exhaust
08-11432
$168.85
Quantity
SA646592-A11Main Bearing Set
08-11463
$566.00
Quantity
SA52012912Rocker Arm Bushing (One Piece Bushing)
08-11102
$12.50
Quantity
SA5306586Connecting Rod Bushing
08-11142
$13.99
Quantity
SA643626-1054Counterweight Pin
08-11422
$17.50
Quantity
SA643626-1042Counterweight Pin
08-11421
$17.50
Quantity
SA643626-1062Counterweight Pin
08-11423
$17.50
Quantity
SA35099816Counterweight Bushing
08-10986
$13.99
Quantity
SA64362916Counterweight Retaining Plates
08-11424
$1.99
Quantity
SA62910416Counterweight Snap Rings
08-11249
$0.81
Quantity
SA62810912Connecting Rod Nuts
08-11239
$7.90
Quantity
MS24665-229
12Connecting Rod Cotter Pins
MS24665-229
$0.33
Quantity
SA631088-.444Camshaft Bolts
08-11299
$6.99
Quantity
SA5363796Crankshaft Bolts
08-11182
$11.50
Quantity
SA6492054Crankshaft Alternator Face Gear Bolts
08-11475
$9.60
Quantity
SA6419092Crankshaft Alternator Face Gear Lock Plate
08-11397
$8.50
Quantity
MS35756-8 2Woodruff Keys
08-10859
$1.40
Quantity
SA6381724Magneto Drive Rubber Bushings
08-00321
$5.70
Quantity
SA6438736Exhaust Valves
08-03680
$318.00
Quantity
SA629117-16Exhaust Valve Rotocoils
08-11251
$26.50
Quantity
SA65444224Valve Springs - Inner
08-11490
$7.95
Quantity
SA65444112Valve Springs - Outer
08-11489
$12.50
Quantity
SA6300466Piston Pins
08-11261
$87.75
Quantity
SA5000-SC56Piston Rings (For Steel Barrel)
08-11084
$140.80
Quantity
SA65298412Rocker Shafts
08-11488
$27.60
Quantity
SA65294712Rocker Shaft Retaining Bolt Washer
08-11487
$0.67
Quantity
MS90725-1212Rocker Shaft Retaining Bolt
08-10874
$1.11
Quantity
SA641931-10.758Crankcase Through Bolt
08-11398
$102.75
Quantity
SA53100136Cylinder Hold Down Nuts
08-11148
$11.50
Quantity
SA63450512Cylinder Hold Down Nuts
08-11353
$13.50
Quantity
SA6412501Crankcase Nose Seal
08-03675
$62.99
Quantity
Subtotal $0.00
Add to Wishlist

Overview

Continental engines are the culmination of hundreds of parts improvements made over the last six decades.
  • Frequently Purchased With
  • Customers Also Viewed

Reviews

In stock, arrived promptly and well packaged. No issues noted during installation..

Jason H Verified Purchase

SUPERIOR SA531001 NUT, CYLINDER HOLD DOWN

November 18, 2022

Very high quality and complete shipped super fast!

Timothy W Verified Purchase

SUPERIOR SA633570-A5 GASKET SET MAJOR OVERHAUL

October 19, 2022

It worked fine. Can be stretched over the (protected ) propeller hub without heating if OAT is warm (it was about 90F).. takes some technique (that our mechanic had) but no special tools, other than a screwdriver for leverage, on a continental motor. There are several bulletins dealing with installation but it basically needed a non hardening adhesive for the OD and just engine oil for the ID. Bulletin says to run the engine to check for leaks but you should not do anything for 24 hours to let the sealant set (I found out the hard way!).
