COMPREHENSIVE GUIDE TO AIRFOIL SELECTIONS

$31.50/Each
Quantity
Add to Wishlist
Part# 13-09036
MFR Model# 0879940387

Overview

Depicts over 500 actual airfoil designs for light aircraft individually described pictorially, graphically, and by specifications, and with each giving: dimensions in span, chord, camber; percent of chord, lift to drag, center of pressure, drag & lift coefficients curves by angle of attack; and some historical information.

Specifications

  • Publisher: Aviation Publications
  • Copyright Date: 1982
  • Edition: Expanded
  • Pages: 167
  • Binding: Paperback
  • Weight: 1.4lbs

Documents

Contents

  • TABLE OF CONTENTS:
  • Detail Design Illustrations
  • Wing Design
  • Engineering Tables
  • Aircraft Hardware Specifications

Reviews

The title should be Comprehensive Reference Guide to Ancient Airfoils. Copyright 1982 but airfoil plots are dated 1919 to 1936. There is almost no discussion, but just plots of the airfoil, L/D, coefficient of lift, coefficient of drag, plotted against AOA. Airfoils from 5 countries are listed. Instead of this, I would recommend starting with Harry Ribletts GA Airfoils which is $19 and updated in 1988. The clearly written General Aviation Aircraft Design by Snoori Gumundsson published in 2014 is far better, but is pricey at $140 for its 1033 pages. This book is very practical, and lists in tabular form good airfoils and how to choose the best one for your design in that 65 page section.

James F
January 3, 2018
